Agitator drives

DST agitator drives are available as overhead drive or bottom mounted drive.

An agitator drive equipped with DST permanent magnetic coupling hermetically seals the agitator, thus preventing any escape of hazardous gases or the ingress of contamination during agitation.

Torque

  • Overhead drive: 0.1 – 15,000 Nm
  • Bottom mounted drive: 0.3 – 1,000 Nm* (* <150 Nm incl. SSiC bearing, further bearings made of steel or plastic on request)

Materials

  • Standard: 1.4435 and 1.4404
  • Stainless steel: 1.4301, 1.4401, 1.4571, 1.4539, 1.4980
  • Hastelloy: 2.4602 (C-22), 2.4610 (C-4), 2.4819 (C-276)
  • Titanium: 3.7035 (Grade 2), 3.7055 (Grade 3), 3.7165 (Grade 5)
  • Many other special materials on request.

Applications

  • Overhead drives
  • Autoclaves
  • PU industry
  • Chemical industry
  • Laboratory industry
  • Bottom mounted drives
  • Food industry
  • Pharmaceutical industry
  • Process industry

Follow us on WeChat for more information

Advantages

  • Overhead drives:
  • Complete unit with motor
  • Compact design for the laboratory technology
  • High pressures and temperatures possible
  • Everything from a single source
  • Customer-specific solutions
  • Bottom mounted drives:
  • Very good surface finish
  • Optionally equipped with speed monitoring
  • Canister flange as screw or welding flange
  • Various materials are available
  • Customer-specific solutions
